• 1.Measuring the thickness of non-magnetic coating on the magnetic metal substrate.
  2.Measuring the thickness of the non-metallic coating on the non-magnetic metal substrate.
  3.Automatically identifying the non-magnetic metal substrate and magnetic metal substrate.
  4.Single measurement, continuous measurement and differential measurement available.
  5.Zero-point calibration, Offset Calibration and basic calibration available.
  6.Metric and imperial units of measurement optional.
  7.LCD backlight.
  8. Automatic shutdown.

• Measurement ranges	0 ~ 1800μm/70.8mil/1.8mm
  Resolution	(0.1μm(<100μm),1μm(≥100μm))/0.1mil/0.001mm
  Measuring error	≤150μm， ±5μm >150 μm，±(3%H+1μm）
  Minimum diameter of magnetic substrate	12mm
  Minimum thickness of magnetic substrate	0.5mm
  Minimum curvature radius of convex magnetic substrate	2mm
  Minimum curvature radius of concave magnetic substrate	11mm
  Minimum diameter of non-magnetic substrate	50mm
  Minimum thickness of non-magnetic substrate	0. 5mm
  Operating temperature range	-20~40℃(It is recommended to calibrate it again when use in different environments, especially for large temperature difference)
  Operating humidity	10~95%RH
  Power supply	2*1.5V AAA batteries
  Overall dimensions	62*27*121.5mm
  Weight	105.03g



• Please refer to the manual for details
•
• \
